This unit machine is special design for packaging various vegetable like White radish, cucumber, lettuce, cabbage in to plastic bag .The whole machine have the function of automatic product feeding ,weighing ,film bag forming ,bag sealing ,Including date coding ,bag counting .The finished bag is output from conveyor machine which no need manual collect the bag and avoid the bag polluting .
Toepassing:
It is suitable for quantitative weighing of large target weight or large volume materials such as vegetable salad, fruit salad, potatoes, onions, tomatoes, cherry tomatoes and other vegetables and fruits.
Kenmerken:
- Special load cell with high precision and high standard.
- Program recovery function can reduce operation failures, support multi-segment weight calibration.
- No products auto pause function can improve weighing stability and accuracy.
- Linear amplitude can be adjusted independently, can make the feeding more uniform.
- 15 languages available for global markets.
- 100 programs capacity can meet various weighing requirement, user-friendly help menu in touch screen contributes to easy operation.
Inleiding :
Deze machine kan automatisch functies realiseren voor het maken van zakken, vullen, sealen, bedrukken, snijden, enz. Deze machine kan automatisch de zakken bereiken die vullen en sealen.
Deze verpakkingsmachine maakt gebruik van een importservomotor voor filmtoevoer en de mens-machine-interface maakt gebruik van een geavanceerd aanraakscherm. Bediening eenvoudiger en handiger. Alle componenten nemen een internationaal bekend merk aan, PLC is SIEMENS, servomotor is PANASONIC, aanraakscherm is SIEMENS, cilinder en luchtklep is SMC. onderdelen die in contact komen met materiaal, schakelkast, hoofdframe zijn gemaakt van roestvrij staal 304
Technische parameters:
| Model | ZL780 |
| Forming bag type | Pillow bag/gusseted bag |
| Tas lengte | 150-480mm by secondary film pulling the bag length can be longer |
| Zakbreedte | 120-375mm(Side width +front width ) |
| Film breedte | ≤780mm |
| Bag forming speed | 5-15bag/min |
| Air source consumption | 0.8MPa 0.45m3/min |
| Max outer diameter of reel | ¢400mm |
| Core inner dia | ¢75mm |
| macht | 6KW 380V±10% 50Hz |
| Machinegrootte | 1650*1500*1750mm |
| Machine gewicht | 650kg |
